點擊圖片查看原圖產品價格 面議
最小起訂量：10 片 可售數量：100 片
WIFI快速漫游網卡
￥400.00/片
企業名片
WPEQ-256ACN 由 Qualcomm Atheros QCA9882 無線電芯片提供支持，并采用 2×2 WiFi 5 技術，可實現更高的吞吐量性能、可靠性和范圍。它旨在滿足關鍵嵌入式應用程序的苛刻性能要求。
WPEQ-256ACN 將整體吞吐量大幅提升至 867Mbps。利用革命性的 WiFi 5 技術，WPEQ-256ACN 在吞吐量和范圍方面樹立了新的標桿，使其成為消費者和企業應用的理想選擇，例如銷售點、游戲機和醫療設備。
適用應用
STANDARD |
||
| WI-FI | IEEE 802.11ac/a/b/g/n | |
| Chipset | ·Qualcomm Atheros QCA9882-BR4A | |
| Host Interface | WLAN : PCIe | |
RADIO |
||
| Antenna | 2 x IPEX MHF1 connectors | |
| Operating Frequency | 802.11ac/a/b/g/n ISM Band | |
| 2.412GHz~2.484GHz
5.150GHz~5.850GHz *Subject to local regulations |
||
MODULATIONS |
|
| 802.11b | DSSS (DBPSK, DQPSK, CCK) |
| 802.11g | OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| 802.11n | OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| 802.11a | OFDM (BPSK, QPSK, 16-QAM, 64-QAM) |
| 802.11ac | OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM) |
POWER & SENSITIVITY |
||
| WiFi | Power – TX (± 2dBm) | Sensitivity – RX |
| 11b @11Mbps | 20dBm | ≤ -87dBm |
| 11g @ 54Mbps | 16dBm | ≤ -74dBm |
| 11gn HT20 @ MCS 7 | 15dBm | ≤ -70dBm |
| 11gn HT40 @ MCS 7 | 15dBm | ≤ -68dBm |
| 11a @ 54Mbps | 14dBm | ≤ -74dBm |
| 11an HT20 @ MCS 7 | 13dBm | ≤ -71dBm |
| 11an HT40 @ MCS 7 | 13dBm | ≤ -68dBm |
| 11ac VHT80 @ MCS 9 | 10dBm | ≤ -59dBm |
POWER CONSUMPTION |
||
| Continue TX | 1050mA | |
| Continue RX | 480mA | |
ENVIRONMENTAL |
||
| Operating Voltage | DC 3.3V | |
| Temperature Range | -20~ 60°C (Operating) | -30 ~ 75°C (Storing) |
| Humidity(Non-Condensing) | 10~ 85% (Operating) | 5 ~ 90% (Storing) |
SIZE |
||
| Dimension (MM) | 50.8mm(±0.3mm) x 29.85mm(±0.3mm) x 4.1mm(±0.3mm) | |
| Weight | 7.8g | |
SOFTWARE |
||
| Driver | Linux | |
| Security | 64/128-bits WEP, WPA, WPA2,802.1x | |
Miscellaneous |
||
| Warranty Period | 12 Month | |
| HS Code | 8517620050 | |
 |
 |
 |
 |
| USA | EU Region | Japan | Canada |
 |
 |
||
| ROHS | REACH |
